DA98D User Manual
6
Chapter Two Installment
z The products must be stored and installed according to the requirements for environmental
conditions.
z The products can be piled up with a limited number; over-piling shall not be allowed to
prevent the products from being damaged or falling.
z The products must be stored and transported with original package.
z Product shall not be installed when it is damaged or does not have complete parts.
z Fireproof material is needed for the product installment; the product shall not be installed
above or around combustible article to prevent fire.
z Servo drive unit must be installed within electric cabinet to prevent invasion of dust, corrosive
air, conductive matters, liquid, combustible and explosive substances.
z Servo drive unit and servo motor shall avoid vibration. Impact shall be strictly forbidden.
z It is forbidden to draw wire, motor shaft and encoder of the servo motor.
2.1 Environmental Conditions
Items DA98DServo Drive unit GSK SJT Series of AC Servo Motor
Operation
Temperature/
Humidity
0℃～55℃ (no frozen frost)
Less than 90%RH (no dew
condensation)
-10℃～40 (℃ no frozen frost))
90%RH (no dew condensation)
Storage
Temperature/
Humidity
-20℃～80℃
90%RH(no dew)
-40℃～55℃
85%RH ( no dew)
Atmospheric
Environment
Within the control panel, there
shall be not corrosive air,
combustible air, oil fog or dust.
Within the room (no insolation), there shall be
not corrosive air, combustible air, oil fog and
dust.
Height
Less than 1000m above sea
level
Less than 1000m above sea level
Vibration Less than 0.5G(4.9m/s2)10 Hz -60Hz (non-continuous operation)
Degree of
Protection
IP00 IP54
2.2 Installment of Servo Drive unit
z Servo drive unit must be installed in the electric cabinet with good protection.
z Servo drive unit must be installed according to direction and interval as stipulated. Good
conditions for heat radiating should be guaranteed.
z It shall not be installed above or around combustible articles to prevent fire.
1） Installment Environment
（1） Protection
