switch on/off the socket” functions, the socket will control to switch
on or cut off the output according to temperature setting.
If users open the “timed switch on the socket” or “delayed switch
on/off the socket” functions, the temperature control function will only
be valid when power output is switch on (including timed switch on
or delayed switch on time period).
For example: GSM Power Socket is used for the power control of the
heating apparatus. If users set the socket output on when indoor
temperature is bellow 20 degrees and off when indoor temperature
is above 28 degrees. Meanwhile, users set the GSM Power Socket
output is on from 9am to 5pm. In this case, the socket will control to
switch on or off the output according to indoor temperature
automatically from 9am to 5pm duration.
Method
The Master user sends following SMS message in order to:
Enable auto-control the output by temperature: #159#1# (21)
Successful SMS reply
Status: ON/OFF
Temp control: function ON
Temp: **
Mode: Heating/Cooling
Range: LowTemp ~ HighTemp
Then GSM Power Socket can switch on or off the output
automatically according to the temperature range setting.
3.6.2 Set temperature range to switch on/off the output
Description
After successful setting of temperature range, the temperature
parameter will be saved on the socket until GSM Power Socket is
reset to factory settings.
But the “Auto-controlled by temperature” feature is applied only
To Next Page
