6.3 Mechanical Characteristics
Table 6-3
Model
Unit
10kVA
15kVA
20kVA
30kVA
40kVA
Dimension
W×D×H
mm
380*840*1400
380*840*1400
380*840*1400
500*940*1400
500*940*1400
Weight
kg
100
100
100
140
140
Color
---
BLACK, RAL 7021
Protection
Level
IEC60529
---
IP20
6.4 Electrical Characteristics
6.4.1 Electrical Characteristics Input Rectifier
Table 6-4
Item
Unit
Parameter
Grid System
---
3Phases + Neutral + PE,
(sharing neutral with the bypass input)
Rated AC Input Voltage
Vac
380/400/415 std=400V
Input Voltage Range
Vac
304~478Vac (Line-Line), full load;
228V~304Vac (Line-Line), load decreases linearly from
100% to 60% according to the input voltage
Rated Frequency
Hz
50/60
Input Frequency range
Hz
40~70
Input Power factor
---
>0,99
Input Current THDi
%
<4% (full Linear Load) 10-15kVA
<3% (full Linear Load) 20-40kVA
