Assembly
Make sure that you follow all of the instructions in this manual carefully to assemble your eBike cor-
rectly before use.
We recommend that you build your eBike on a large, at and soft surface. You may need to put
something down on the surface to stop your eBike from getting scratched.
Carefully remove all of the packaging and ties from your eBike, as well as the 4 black plastic
wheel protectors and fork spacer. Take care not to damage or scratch the bike.
Check that you have all of the correct parts before you start to assemble your eBike.
See page 6 - 7.
For more information about the names and locations of the different parts of your eBike see page
8 - 11.
Make sure that the battery is removed from the bike before tting any parts.
Make sure that all screws are tightened securely before using your eBike.
For the correct tightening torques see page 69.
Assembly .....................................................................................14
Attaching the handlebars .............................................................15
Attaching the saddle ....................................................................18
How to t the front wheel .............................................................19
Fitting the pedals .........................................................................22
Assembling the front brakes ........................................................23
Adjusting the brake cable ............................................................25
Aligning the brake pads ...............................................................27
Adjusting brake travel ..................................................................28
Attaching the reectors ................................................................30
Assembling the kickstand ............................................................31
Assembling the mudguards .........................................................33
Finding the correct saddle height .................................................37
Adjusting the saddle height ..........................................................38
Adjusting the saddle angle and travel ...........................................39
Storing the Gtech tool .................................................................40
Attaching the battery ...................................................................41
Removing the battery ..................................................................42
