When closed, the quick release lever must lie at against the frame, fork and
saddle clamp, otherwise it could snag on obstructions when the bike is moving.
This could lead to serious injury.
Attaching the saddle
The seat tube has a quick-release tting on it to make it easier to attach and adjust the saddle’s height.
To operate the quick-release, follow these instructions:
Refer to page 38 for adjusting the saddle to the recommended height and position.
1. Pull back the quick-release lever.
2. Insert the saddle post into the frame.
Drop the saddle’s seat post down to its lowest
position and make sure that the saddle is in line
with the eBike’s frame.
Check that the saddle cannot move once the
quick-release is closed. If it does move, tighten
the adjusting nut, until you need to use the palm
of your hand to close the quick-release lever.
Close the quick-release by rmly pushing on the
quick-release lever, so that it lies at against the
frame.
2
1
