Push the quick-release lever in towards the
frame of the bike, so that it is fully closed.
Position the quick-release axle into the front
dropout.
Tighten the adjustment nut by turning
it clockwise approximately 5 full rotations.
Attaching the front wheel
Once complete rotate the wheel and ensure that there is no rubbing or scraping
noises from the brake. If there are please refer to page 44.
Brake rotors are sharp, please keep ngers clear of the rotor to avoid injury.
Place the frame upside down on a at surface, resting on the saddle and the handlebars. You may
need to put something down on the surface to stop your bike frame from getting scratched.
