Check to see whether the braking surface of the
pads have been worn. If they are worn down to a
thickness of 0.5 mm, or if the brake pad presser
springs are interfering with the disk, replace the
brake pads.
Do not use oil or cleaning uids on the calipers or brake pads. If this happens they will
need to be replaced.
Combine the new or cleaned spring and brake
pads as pictured above. The spring should be on
the inside and brake pads on either side.
Insert the spring and brake pads into the caliper. Reinsert and re-bend the pin to it’s original state.
Ensure genuine Shimano pads are used:
G01S (Resin) replacement pads for front and rear. 180mm (sm-RT66) for Rear and
180mm (sm-RT64) for Front.
