OPERATION
71
PSU 30-50
30V
30V
30V
30V
50A
100A
150A
200A
PSU 40-38
40V
40V
40V
40V
38A
76A
114A
152A
PSU 50-30
50V
50V
50V
50V
30A
60A
90A
120A
PSU 60-25
60V
60V
60V
60V
25A
50A
75A
100A
PSU 80-19
80V
80V
80V
80V
19A
38A
57A
76A
PSU 100-15
100V
100V
100V
100V
15A
30A
45A
60A
PSU 150-10
150V
150V
150V
150V
10A
20A
30A
40A
PSU 300-5
300V
300V
300V
300V
5A
10A
15A
20A
PSU 400-3.8
400V
400V
400V
400V
3.8A
7.6A
11.4A
15.2A
PSU 600-2.6
600V
600V
600V
600V
2.6A
5.2A
7.8A
10.4A
Master-Slave Parallel Connection
Analog Control
Connection
To operate the power supplies in parallel with the
analog connectors, connect the analog connectors
on the master and slave units as shown in the
diagrams below. Alternatively, preconfigured
cables can be used:
PSU-01C: 1 master with 1 slave
PSU-02C: 1 master with 2 slaves
PSU-03C: 1 master with 3 slaves
