GYS E1 - Setting Up the Equipment; General Setup and Ventilation; Maintenance and Recommendations

EN
21
Operating manual
E1 - E2 - E3 GYS AUTO
Translation of the original
instructions
SETTING UP THE EQUIPMENT
• Place the welding power source on a oor with a maximum inclination of 10°.
• Provide su󰀩cient space to ventilate the welding power source and access the controls.
• Do not use in an area with conductive metal dust.
• The welding power source should be protected from heavy rain and not exposed to direct sunlight.
• The machine benets from an IP21 protection index, which means:
- its dangerous parts are protected from being entered by objects greater than 12.5 mm and,
- Protection against vertically falling drops
Stray welding currents can destroy earthing conductors, damage electrical equipment and devices and cause component parts
to overheat leading to res.
- All welding connections must be rmly secured and regularly checked!
- Make sure that the item’s attachment is rm and secure, without any electrical problems!
- Join together or suspend any electrically conductive parts of the welding source such as the frame, trolley and lifting systems so that they are
insulated!
- Do not place other equipment such as drills or grinding devices etc. on the welding source, trolley, or lifting systems unless they are insulated!
- Always place welding torches or electrode holders on an insulated surface when not in use!
Power cables, extension cables and welding cables should be fully unwound to avoid overheating.
The manufacturer assumes no responsibility for damage to persons or objects caused by improper and dangerous use of this
equipment.
MAINTENANCE / RECOMMENDATIONS
 Maintenance should only be carried out by a qualied person. Annual maintenance is recommended.
 Switch o󰀨 the power supply by pulling the plug and wait two minutes before working on the equipment.. Inside the macine, the
voltages and currents are high and dangerous.
• Regularly remove the cover and blow out any dust. Take advantage of the opportunity to have the electrical connections checked with an insulated
tool by a qualied professional.
 Regularly check the condition of the power cord. If the power cable is damaged, it must be replaced by the manufacturer, the after sales service
team or an equally qualied person to avoid any danger.
• Leave the welding power source vents free for air intake and outow.
• Do not use this welding power source for thawing pipes, recharging batteries/storage batteries or starter motors.
INSTALLATION - USING THE PRODUCT
Only experienced personnel, authorised by the manufacturer, may carry out the machine’s set-up. During set-up, ensure that the power source is
unplugged from the mains. Series or parallel power source connections are not allowed. It is recommended to use the welding cables supplied with
the unit in order to obtain the optimum product settings.
DESCRIPTION
The unit is a semi-automatic «synergic» welding unit, ventilated for welding (MIG or MAG). This machine is recommended for welding steel, stainless
steel, aluminium and the brazing. Its adjustment is quick and easy with its «synergic» mode.
DESCRIPTION OF THE EQUIPMENT (II)
E1
1- Reel support Ø 200/300 mm 8- Euro connector (torche)
2- Accessory box hatch 9- Storage space
3- Cable support 10- Gas connector
4- Torch support 11- Mains cable (6.25 m)
5- HMI 12- Bottle holder 4 m3
6- START/STOP switch 13- USB hatch
7- Ground clamp cable (3.5 m) 14- Wire-feed motor
