Operating manual
E1 - E2 - E3 GYS AUTO
Translation of the original
instructions
E2
1- Gas connector (torch 1) 10- Euro connector (torch 1)
2- Gas connector (torch 2) 11- Euro connector (torch 2)
3- Reel support Ø 200 mm (torch 1) 12- Bulkhead connector for gas
4- Reel support Ø 200/300 mm (torch 2) 13- Mains cable (6.25 m)
5- Cable support 14- Bottle holder 4 m3 or 2 x 4 m3
6- Torch support 15- USB hatch
7- HMI 16- Wire-feed motor (torch 1)
8- START/STOP switch 17- Wire-feed motor (torch 2)
9- Ground clamp cable (3.5 m)
E3
1- Gas connector (torch 1) 11- Ground clamp cable (3.5 m)
2- Gas connector (torch 2) 12- Euro connector (torch 1)
3- Gas connector (torch 3) 13- Euro connector (torch 2)
4- Reel support Ø 200 mm (torch 1) 14- Euro connector (torch 13
5- Reel support Ø 200 mm (torch 2) 15- Bulkhead connector for gas
6- Reel support Ø 200 mm (torch 3) 16- Mains cable (6.25 m)
7- Cable support 17- Bottle holder 4 m3 or 2 x 4 m3
8- Torch support 18- USB hatch
9- HMI 19- Wire-feed motor (torch 1)
10- START/STOP switch 20- Wire-feed motor (torch 2)
21- Wire-feed motor (torch 3)
HUMAN-MACHINE INTERFACE (HMI)
HMI
Please read the Interface (HMI) manual which is part of the equipment’s user literature.
POWER SWITCH
The material is supplied with a 16A plug type CEE7/7 and must only be used on a single-phase electrical installation 230V (50-60 Hz) with 3 wires
including one connected to earth.
The absorbed eective current (I1e) is shown on the device for optimum operating conditions. Check that the power supply and its safeguards (fuse
and/or circuit breaker) are compatible with the electric current being used. In some countries, it may be necessary to change the plug to allow the use
at maximum settings.
• The power source is designed to operate on 230 V -20% +15%. The machine goes into protection mode if the supply voltage is below 185 Ve or
above 265 Ve. (an error code will appear on the display screen).
• The power is switched on by pressing the START/STOP switch (On), conversely switching o is done by pressing the same switch (O). Warning!
Never disconnect the machine from the power supply while the machine is charging.
CONNECTING TO A POWER SOURCE
This equipment can be operated with electric generators provided that the auxiliary power supply meets the following requirements:
- The voltage must be alternating, and the RMS value must be 230 V -20% +15%, with peak voltage below 400V,
- The frequency must be between 50 and 60 Hz.
It is imperative to check these requirements, as many generators generate high voltage peaks that can damage these machines.
USING EXTENSION LEADS
All extension leads must be of a suitable length and width that is appropriate to the equipment’s voltage. Use an extension lead that complies with
national safety regulations.
Input voltage Extension lead cross section (<45m)
230 V 2.5 mm²
SETTING UP THE REEL
a b
- Remove the nozzle (a) and contact tube (b) from your MIG/MAG torch.
