technical data
file: n:\article\cos14310m5-v1_08hpc-en\20150130_cos14310m5-v1.08hpc-en_instructions_for_use_h-p-cosmos_treadmill.doc
© 2015 h/p/cosmos sports & medical gmbh author: fh email@h-p-cosmos.com created 30.01.2015 printed 30.01.2015 page: 165 of 216
stellar
®
, quasar
®
, pulsar
®
locomotion
®
190/65 med
stellar
stellar lt
quasar
quasar lt
stellar med
stellar med lt
quasar med
quasar med lt
pulsar
pulsar lt
locomotion 190/65 E med
locomotion 190/65 DE med
Dimension of running surface
length x width
1700 x 650 mm
1900 x 650 mm
Dimension frame
length x width x height
2300 x 1050 x 1450 mm
(UserTerminal + 150 mm width)
2500 x1050 x
1450 mm
UT: + 150 mm
2500 x1150 x
1450 mm
seats: + 400 mm
Track access height from floor
230 mm
Weight of device
310 kg
315 kg
330 kg
335 kg
345 kg
560 kg
Substitut. load to floor (EN 1991)
2.5 kN/m²
2.5 kN/m²
2.6 kN/m²
2.6 kN/m²
2.5 kN/m²
3.3 kN/m²
Load to floor on each support
1.5 kN
1.5 kN
1.6 kN
1.6 kN
1.6 kN
2.2 kN
Max. permissible user weight
300 kg (deviation on request specially made), max. user weight for safety arch: 210 kg
Environmental conditions:
Transport and storage
temperature: –30...+50 °C, humidity: 0...95 % - without condensation
barometric pressure: 700...1060 hPa
Environmental conditions:
Operation
temperature: +10...+50 °C (deviation on request), humidity: 30...70% - without condensation
(up to 95% on request), barometric pressure: 700...1060 hPa
Maximum operating altitude: approx. 10,000 feet (3000m), without pressurization
Pollution degree
Degree 2: Normally only nonconductive pollution. Temporary conductivity caused by condensation is to be expected.
Central lubrication system
manual
Number of stored programmes
6 training profiles / 10 test profiles / 8 user definable profiles
RS232 Digital interface /
serial port
(USB-converter optional)
COM1: standard
COM2: optional
COM3: optional (standard for service)
COM4: optional
COM1&2:
standard
COM3: optional
(for service)
COM4: n.a.
(W.I.N.D.)
COM1, COM2:
standard
COM3: n.a
(Touchscreen)
COM4: n.a.
(W.I.N.D.)
Heart rate measurement and
heart rate dependent endurance
control
POLAR, 1 channel receiver, ECG precisely
Polar W.I.N.D. with WearLink
transmission range approx. 10 m
PC software
h/p/cosmos para control
®
included
options: h/p/cosmos para graphics
®
and h/p/cosmos para analysis
®
incl. para
control
®
& para
graphics
®
optional: para
analysis
®
incl. para control
®
optional: para
graphics
®
& para
analysis
®
Reverse belt rotation
option
standard
Safety Arch with chest belt
system***
option
Handrails
options: short, long, crossbar (standard)
adjustable
Arm support
option
n.a
Additional keyboard
option
standard
* Overload and weak power supply (under voltage) could lead to higher discrepancies concerning the speed display or dripping of the fuse.
** The time of operation of the elevation motor (TO = 15 %) converts to approx. 5 full elevation cycles. Overload can result in temporary tripping of the fuse,
but can be used again after short cool down period. Treadmills of the h/p/cosmos saturn series built approx. before January 2007 have a maximum
elevation of 25 %.
*** For maximum stress tests and with oversize running machines (track sizes) a safety facility (e.g. a safety arch with chest belt system) is necessary and
highly recommended. When using a front-bar handrail (crossbar), the speed is limited to 5 km/h for safety reasons. Data of weight and measurements can
deviate.
Ask for further details and optional equipment or visit www.h-p-cosmos.com. Subject to technical alterations without prior notice. E & OE.
