h/p/cosmos pluto - Plug Assignment at the Userterminal

safety, installation and commissioning
file: n:\article\cos14310m5-v1_08hpc-en\20150130_cos14310m5-v1.08hpc-en_instructions_for_use_h-p-cosmos_treadmill.doc
© 2015 h/p/cosmos sports & medical gmbh author: fh email@h-p-cosmos.com created 30.01.2015 printed 30.01.2015 page: 99 of 216
7.4.6.4 Plug assignment at the UserTerminal
If the UserTerminal was disassembled during transport, please connect the cables according to the following
illustration:
Devices with MCU5 control unit (since manufacturing date 02/2010)
