technical data
file: n:\article\cos14310m5-v1_08hpc-en\20150130_cos14310m5-v1.08hpc-en_instructions_for_use_h-p-cosmos_treadmill.doc
© 2015 h/p/cosmos sports & medical gmbh author: fh email@h-p-cosmos.com created 30.01.2015 printed 30.01.2015 page: 167 of 216
pulsar
®
3p
locomotion
®
190/65 3p med
quasar
3p
quasar
3p lt
pulsar 3p
pulsar 3p lt
locomotion 190/65
-3p E med
locomotion 190/65
-3p DE med
Dimension of running surface
length x width
1700 x 650 mm
1900 x 650 mm
Dimension frame
length x width x height
2300 x 1050 x 1450 mm
(UserTerminal + 150 mm width)
2500 x1050 x 1450 mm
(UserTerminal + 150 mm width)
2500 x1150 x 1450 mm
(seats + 400 mm width)
Track access height from floor
230 mm
Weight of device
355 kg
385 kg
600 kg
Substitut. load to floor (EN 1991)
2.7 kN/m²
2.6 kN/m²
3.1 kN/m²
Load to floor on each support
1.6 kN
1.7 kN
2.3 kN
Max. permissible user weight
300 kg (deviation on request specially made)
max. user weight for safety arch: 210 kg
Environmental conditions:
Transport and storage
temperature: –30...+50 °C, humidity: 0...95 % - without condensation
barometric pressure: 700...1060 hPa
Environmental conditions:
Operation
temperature: +10...+50 °C (deviation on request), humidity: 30...70% - without condensation
(up to 95% on request), barometric pressure: 700...1060hPa
Maximum operating altitude: approx. 10,000 feet (3000m), without pressurization
Pollution degree
Degree 2: Normally only nonconductive pollution. Temporary conductivity caused by condensation is to be expected.
Central lubrication system
manual
Number of stored programmes
6 training profiles / 10 test profiles / 8 user definable profiles
RS232 Digital interface / serial
port
(USB-converter optional)
COM1 and COM2: standard COM3: optional (standard for service) COM4:
n.a. (used for POLAR W.I.N.D.)
COM1 and COM2: standard
COM3: n.a. (used for UserTerminal
TouchScreen) COM4: n.a. (used for
POLAR W.I.N.D.)
Heart rate measurement and
heart rate dependent endurance
control
POLAR W.I.N.D. with WearLink
transmission range approx. 10 m
PC software
h/p/cosmos para control
®
and
h/p/cosmos para graphics
®
included
Reverse belt rotation / downhill
standard
Safety Arch with chest belt
system***
option
Handrails
options: short, long, crossbar (standard)
as standard: adjustable with gas
spring support
Arm support / additional keyboard
option
no arm support; additional keyboard
is standard
* Overload and weak power supply (under voltage) could lead to higher discrepancies concerning the speed display or dripping of the fuse.
** The time of operation of the elevation motor (TO = 15 %) converts to approx. 5 full elevation cycles. Overload can result in temporary tripping of the fuse,
but can be used again after short cool down period. Treadmills of the h/p/cosmos saturn series built approx. before January 2007 have a maximum
elevation of 25 %.
*** For maximum stress tests and with oversize running machines (track sizes) a safety facility (e.g. a safety arch with chest belt system) is necessary and
highly recommended. When using a front-bar handrail (crossbar), the speed is limited to 5 km/h for safety reasons. Data of weight and measurements can
deviate.
Ask for further details and optional equipment or visit www.h-p-cosmos.com. Subject to technical alterations without prior notice. E & OE.
