In case of any problems / malfunction:
Make sure that all expulsion fuses in the external
switching cabinet are switched on. Opening of the
device must only be performed by authorized
technicians.
Switch on the running machine by using the main
switch at the right side of the external UserTerminal
(control unit). The main switch has to be turned 90°
clockwise as shown in the picture.
The main switch can be secured against
unauthorized access with a padlock.
Press the “power on” push button.
After a delay time (green light is blinking) of 1 minute
the green light stops blinking and stays illuminated.
Now the hydraulic for the elevation system and the
running machine are powered on and ready for
getting started.
