7-1
7 Installing cable management brackets
To prevent the cable management
brackets from blocking the mounting bracket installation holes
on the rack posts, install cable management brackets after the device is mounted in the rack.
To install a cable management bracket, insert a cable guide to the cable guide hole in the pillow
block.
Figure7-1 Cable management brackets
