2-1
2 Installing the device
Rack-mounting the device
CAUTION:
The device is heavy. For stability, install it at a lowest possible position.
Attaching slide rails to the rack
Attach the required slide rails to the rack before you mount the device in the rack. For more
information about attaching slide rails, see the slide rail installation guide.
Make sure the slide rail installation positions are at the same height on the four rack posts.
Table2-1 Applicable slide rails
Device
model
Chassis
weight
Max. chassis
weight (fully
configured)
Applicable slide rails
Slide rail
model
Adjustment range
Occupied
rack
space
M9000-X06
36 kg (79.37
lb)
120 kg (264.55
lb)
LSVM1BSR10
630 mm to 900 mm
(24.80 in to 35.43 in)
1 RU
M9000-AI-X
06
36 kg (79.37
lb)
120 kg (264.55
lb)
LSVM1BSR10
630 mm to 900 mm
(24.80 in to 35.43 in)
1 RU
M9000-X10
47 kg (103.62
lb)
220 kg (485.01
lb)
LSXM1BSR
630 mm to 900 mm
(24.80 in to 35.43 in)
1 RU
LSTM2KSGD0
500 to 800 mm (19.69
to 31.50 in)
2 RU
M9000-AI-X
10
47 kg (103.62
lb)
220 kg (485.01
lb)
LSXM1BSR
630 mm to 900 mm
(24.80 in to 35.43 in)
1 RU
LSTM2KSGD0
500 to 800 mm (19.69
to 31.50 in)
2 RU
Mounting the device in a rack
CAUTION:
•
When you move the device to a low temperature environment from a high temperature
environment, condensation might occur. Before installing the device, please dry the device to
prevent the internal components from being damaged because of short circuit.
•
After you place the device on the slide rails
, do not leave go of your hands immediately because
this might tip the device, damaging the device or even causing bodily injury.
To mount the device in a rack:
