11 Appendix A Chassis views
This document is applicable to H3C SecPath M9000-X multiservice security gateway series and
H3C SecPath M9000-AI-X multiservice security gateway series.
Table11-1 H3C SecPath M9000-X and M9000-AI-X multiservice security gateway series
models
Gateway series
Model
M9000-X
M9000-X06
M9000-X10
M9000-AI-X
M9000-AI-X06
M9000-AI-X10
The main components of the device include supervisor engine modules (also called MPUs),
interface switch modules, interface modules, firewall modules, switching fabric modules, fan trays,
and power supplies.
M9000-X06/M9000-AI-X06
Figure11-1 Front view
(1) MPU section
(2) Interface switch module section
1
2
Slot
0
Slot
1
Slot 2
Slot 3
Slot 4
Slot 5
