Haas UMC-750 User Manual

Set the X-, Y-, and Z-Axis Work Offsets with WIPS
46
7.4 Set the X-, Y-, and Z-Axis Work Offsets with
WIPS
If you are not using the WIPS system, go to the Set the X-, Y-, and Z-Axis Work Offsets
Manually section, starting on page 41.
NOTE: Make sure that the tool setting probe and the work probe are
calibrated. Refer to the Haas WIPS manual (96-10002) for the
calibration procedure.
F7.7: UMC-750 Work Offset with WIPS

Haas UMC-750 Specifications

General

Machine Category	Universal Machining Center
C Axis Travel	360 degrees
Tool Capacity	40+1
Travels X Axis	30 in (762 mm)
Travels Y Axis	20 in (508 mm)
Travels Z Axis	20 in (508 mm)
Spindle Speed	8100 RPM
Spindle Motor	30 hp (22.4 kW) vector drive
Spindle Taper	40
Control	Haas
Tool Changer Capacity	40+1
