Section 1 Specifications
Specifications are subject to change without notice.
Meter specification Details
Dimensions 3.5” W x 8” H x 2” D (90mm x 204mm x 50mm)
Weight 3.0 lbs (1.3 Kg)
Battery requirements 4-ANSI -ISA or IEC-LR6 (AA Alkaline)
Power consumptions 1W backlight on
Battery life Up to 200 continuous 10 hour advance of low battery warning
Storage temperature -20 to +60 °C (4 to 140 °F)
Operating temperature Maximum range between +45 to + 60°C (115 to 140 °F)
Input connectors
All models have built-in temperature connectors for sensors.
The handheld series have ISFET (8-pin) connectors, BNC with
phone jack temperature connectors, 12 pin conductivity
connectors
Languages English
Temperature correction Off, automatic and manual (parameter dependent)
Measurement Continuous measurement
Protection rating IP67
pH
Calibration
Up to five points with automatic buffer recognition 1.68, 4.01,
6.86, 7.00, 9.18, 10.01, 12.45
Accuracy ±0.01 pH
Resolution 0.01 pH
Range 0.00 to 14.00
mV
Calibration None
Accuracy 0.1 mV
Resolution Auto ranging 0.1 and 1
Range Auto ranging ± 199.9 mV to ± 1999 mV
Temperature
Calibration None
Accuracy ±0.5 °C
Resolution 0.1 °C 0.1 °F
Range -0 to 100 °C (Display °C or °F)
