11
Installation
3.2.2 Install the charger
1
1. Push the slide switch (item 2, Figure 3) on the back of the charger up and remove the
adapter (item 3, Figure 3).
2. Fix the required adapter to the charger, until it audibly locks into place.
3. Insert the charging plug (item 3, Figure 4) into the charging socket (item 4, Figure 4)
of the instrument.
4. Connect the power (100–240 V~/50–60 Hz).
Figure 2 Inserting the rechargeable batteries
1 Catch 4 Battery holder
2 Battery compartment 5 rechargeable Batteries
3 Battery clip 6 Cap
1
The battery charger must agree with local and national safety regulations and may not be part of the shipment. If the charger
is not part of the shipment, charge the batteries with a charger available in your country. Make sure that the charger agrees
the battery specifications.
WARNING
Risk of fire and explosion.
Only use the battery charger to charge the rechargeable NiMH batteries, while batteries inside
the instrument.
