Advanced Operations
TEST/MAINT
Default value: DISABLED
DISABLED: Normal operation mode
ENABLED: Sets the TEST/MAINT bit (0x0040) of every status register of every configured slave
to indicate the “Service” mode.
VERSION Displays the current software version of the Profibus network adapter card.
LOCATION Displays the current location.
SYSTEM SETUP
NETWORK MODULES
FIELDBUS
Figure 65 Profibus simulation mode
1 Time (x-axis) 4 Minimum
2 Period 5 Maximum
3 Period 6 Simulated value (y-axis)
Table 37 Color/line code for Figure 65
First floating point value
