Hach sc1000 User Manual

58
Standard Operations
5.4 The Main menu display
If the MAIN MENU button (from the pop-up toolbar) is selected, the main menu display is
opened. The main menu display allows the user to view the probe status, configure the
probe setup, system setup and perform diagnostics. The menu structure of the main
menu may vary, depending on the configuration of the system.
Figure 41 Main menu (Menu item language depends on the selected display language)
1 LEFT/RIGHT arrow button—Moves back and forth in the
menu structure.
4 HOME button—Moves to the main measurement screen
from any other screen. This button is not active in
menus where a selection or other input must be made.
2
ENTER button—Accepts an input value, updates, or
accepts displayed menu options.
5 UP/DOWN arrow—Scrolls the menu items.
3
FAVORITES button—Displays/Adds favorites.

Hach sc1000 Specifications

General

Operating Temperature	-20 to 60 °C (-4 to 140 °F)
Inputs	Up to 2 digital or analog sensors
Outputs	2 analog, 2 relay
Communication	Modbus
Power Supply	100-240 VAC
Enclosure Rating	IP66, NEMA 4X
