Hach sc1000 - Section 3 Installation; Mechanical Installation and Mounting

11
Section 3 Installation
DANGER
Electrocution hazard. Only qualified personnel should conduct the tasks described
in this section of the manual.
3.1 Mechanical installation
Figure 1 Probe module with display module
1 Probe module 3 Display module
2 LED indicator 4 Connector, display module to probe module
