hager HR551 - Dimensions

Appendix
Dimensions
Maximum height 2000 m
Degree of protection IP30
Conductor cross-section 2.5 mm²
Dimensions 52.5 x 118 x 74 mm
Standard IEC60947-2-M/IEC60755
10.2 Dimensions
Dimensions for HR55x
90
45
44
52.5 74
118
Fig. 47: Dimensions for HR55x
46 Fehlerstromschutz-Relais
