Haier LTF47K1a - Page 9

| HD Ready LCDTV | User Manual |
p.07
KNOW YOUR MACHINE
F
Vol -: Press to decrease the Volume. In Menu mode, press to decrease a set-
ting.
G
CH+:Presstogotothenexthigherchannel.InMenumode,functionsasthe
uparrow.
H
CH-:Presstogotothenextlowerchannel.InMenumode,functionsasthe
downarrow.
I
PowerButton:UsethisbuttontoswitchyourLCDTVon/off.
J
CommonInterfaceSlot:FunctionwhenPCCardorExpressCardisinCOM-
MON INTERFACE slot of the set. Please refer to your plug-in card manual for
detail information.
K
/
L
AVinput:connecttheVIDEOrecordersorDVDplayerswithstandardcom-
posite output and audio output signal.
M
S-videoInput:ConnectthevideoforaS-Videodevicetothisjack,andcom-
patiblewithcomposite/audioinput.
N
USBInput:ThisTVsetcansupportMultimediainputfor.MP3and.JPEGle.
O
HeadphoneOutput:Connecttoheadphones(32Ω).
P
HDMIInput:HighDenitionMultimediaInterface.Connecttodeviceswith
digitalsignalsandcanbeusedwithPCorHDTVvideosignals.
Q
VGA Input: Connect to VGA analog signals sources.
R
Component Input: The YPbPr video signal can be used if connecting through
thecomponentvideoport.ForexampleProgressiveScanDVDplayers,
HiscaleHDTVDecoders,andsatellitereceivers,obtainvideowithmaximum
resolution using YPbPr and L/R audio signals.
S
SPDIF: SPDIF is highly recommended for high quality digital sound output.
T
AntennaInput:ConnectstoTVRFsignals(antenna/CATV).
U
SCART:TheleftoneisFullSCARTwithtransmitsRGB,S-VideoandCVBSin
andCVBStunerout,therightoneishalfSCARTwhichtransmitsS-Videoor
CVBS in and CVBS monitor out.
V
PowerConnector:ConnectthepowercordintotheACINsocketfoundatthe
back of the TV.
W
PCAudioInput:PCaudiosupports3.5mmJack.
X
HDMIInput:HighDenitionMultimediaInterface.Connecttodeviceswith
digitalsignalsandcanbeusedwithPCorHDTVvideosignals.
