Driving performance
Driving speed, forwards/reverse kph 8.6/4.8
Working speed, maximum, forwards kph 7.0
Climbing capacity, transport mode (max. 1 min) % 20
Climbing capacity, work mode (max. 5 min) % 6
Turning circle diameter, outer M 3.35
Turning in aisle: minimum aisle width M 2.40
Operating time with one battery charge h ca. 3.6
Traction drive
Drive motor (P2) W 2000
Gear oil filling l/SAE 2.6/SAE 90
Axles and wheels
Wheelbase cm 115
Gauge, rear cm 88
Wheels, diameter/width mm 310/120
Specific wheel pressure at permissible gross total weight, front/rear N/mm² 1.04/0.95
Wheel nuts, tightening torque front/rear Nm 140/140
48
Technical Data
