Brakes
Service brake: hydraulisch
Drum brakes at rear, with automa
tic adjustment: diameter/width mm 180/40
Brake fluid (e.g. ATE) l 0.3
Parking brake:
Cable brake at rear, adjustable: diameter/width mm 180/40
Tank volume
Fixed panel tank: solution / waste water l 174/174
Flow rate, adjustable from/to l/min. 1.3/7.0
Brush head
No. of brushes Piece 2
Brush diameter cm 53
Brush speed rpm 210
Brush motor output (P2)/speed W/rpm 2 x 700/1750
Brush pressure, normal/increased kg 44/54
Specific contact pressure normal/increased N/cm² 0.14/0.17
Suction turbines
Power consumption/speed W/rpm 635/13867
Air flow rate
m
3
/h
240
Vacuum mbar (mm WS) 203 (2030)
49
Technical Data
