HAKO Jonas 1200 E - Page 10

Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
Jonas 1200V
Jonas 1200D
Jonas 1200E
Cylindrical broom
Length / diameter mm 800 / 430 800 / 430 800 / 430
Wear limit mm 350 350 350
Speed rpm
500 ± 20 500 ± 20 500 ± 20
Distance between sweeping marks mm 70 + 10 70 + 10 50 + 5
Qty. of bristles qty. 12 V-shape 12 V-shape 12 V-shape
Standard bristling PA PA PES
Sealing strip ground clearance (broo
m compartm.)
left / right / rear mm 1 / 1 / 4 1 / 1 / 4 1 / 1 / 4
front mm 0 0 0
Side broom
Diameter mm 600 600 600
Speed rpm 85 85 85
Standard bristling PA PA PE
Dirt hopper
Hopper volume l 130 130 130
Wheels
Front wheel drive (solid rubber) 4.00-4 4.00-4 4.00-4
Rear wheels (pneumatic) 4.00-8 4.00-8
Inflation pressure bar 6 6
Optional rear wheel option (solid rubber) (Standard E) 4.00-8 4.00-8 4.00-8
