Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
Jonas 1200V
Jonas 1200D
Jonas 1200E
Engine
Manufacturer Briggs&Stratton Lombardini
Type Vanguard V-Twin LDW 502
Work cycles / quantity of cylinders 4-stroke / 2 4-stroke / 2
Capacity cm³ 480 505
Power (at 2,550 rpm) kW 8.2 6.3
Service speed (all consumers on) rpm 2,550 + 50 2,550 + 50
Fuel tank capacity l 25 25
Consumption l/h 2.5 1.25
Engine oil / filling Type / l 15W-40 / 1.5 15W-40 / 1.5
Spark plug Champion RC 12
YC
Hydraulic system
Hydraulic fluid (e.g. Mobiloil) DTE 15 M DTE 15 M DTE 15 M
Tank capacity l 22 22 13
Electric
al system
Starter battery V / Ah 12 / 74 12 / 45 (24 / )
Generator A 13 13
Total output kW 3.10
Output of drive motor kW 1.10
Output of hydraulic drive kW 2 x 1.00
Noise emission value
Sound pressure level acc. to DIN IEC 60335-2-72 dB(A) 78 79 71
Sound power level acc. to DIN IEC 60335-2-72 dB(A) 94 95 88
