Operation
3.1.3 Squeegee
The squeegee (Fig. 7/1), which is
hoo
ked in and can move, is lowered by
means of a hand lever and adapts per-
fectly to the floor through the sealing
strips. The suction turbine vacuums up
the waste water from the floor.
3.1.4 Recovery tank
The waste water which is vacuumed up
is fe
d from the squeegee to the recov-
ery tank (Fig. 7/2) via a suction hose. A
hand-held suction hose is available as
an option to clean and vacuum up solu-
tion from inaccessible areas.
3.1.5 Power flow / traction drive
The hand-guided Scrubmaster B45 is
optimal
ly supported by the power flow
of the brush drive. The Scrubmaster
B45 CL is provided with a continuously
adjustable traction drive. The driving
speed, driving direction and dynamic
deceleration are controlled by the elec-
tronic drive control.
Fig.7
2
1
