HAKO Scrubmaster B45 - Rotary Brush Head

56
Maintenance and Service
5.10 Rotary brush head
1 Slotted-head screw
2C
over
3 Waste container
4 Deflector roller
5Catch
6Brushes
7 Sealing strips
8 Spray jets
9 Knurled screws
Fig.20
