HAKO Scrubmaster B45 - Operating Elements on the Machine

32
Operation
3.2.2 Operating elements on the
machine
1 Solution tank filling neck
2 Squeegee lift lever
3 Solution filter
4 Solution draining hose
5 Power supply line to charger
6 Brush head lift foot pedal
7 Waste water draining hose
8 Hand valve for water dosage 
(Scrubmaster B45 only)
Fig.11
3
14
2
8
5
6
7
