*#1 :-%Owner’s Manual
12
End Block
WHEEL
35. PITCH BEND Wheel
Slides the pitch up or down.
The pitch goes up when moved up, and goes down when moved
down.
36. MODULATION Wheel
On this keyboard, this is used mainly to send MIDI information
to connected MIDI equipment.
LESLIE
37. LESLIE BRAKE Button
This button selects whether to produce sound from the stopped
rotor (=Brake) or not to use the Leslie effect (= Through) when
the LESLIE ON(38) Button is “off”.
Brake is ON when the LED is on.
38. LESLIE ON Button
When it is turned ON, the rotor turns and the sound come from
the Rotor.
When the lamp is lighting, it is ‘ON’.
39. LESLIE FAST Button
Changes the speed of the Rotor from Slow to Fast and vice versa.
It is FAST when the LED is on.
KEYBOARD
40. PRESET Key
This is used to select the Combination Presets.
The Bank is selected by pressing this key, holding down BANK
(8).
The selected BANK/PRESET is indicated by the LED above the
Preset Key.
The “C” key is used to cancel all presets or drawbar settings.
41. MANUAL KEYBOARD
This keyboard contains 61 waterfall shaped keys.
Keyboard is velocity sensitive.
35
36
37 38 39
40 41
