5. Remove the landing gear straps and landing gear from the
fuselage. Using a 1/16′′ drill bit, drill four 1/16′′ holes as
marked in the previous step.
6. Reposition the two main landing gear struts and the landing
gear mounting straps. Using the four 2.6mm self-tapping screws
from the hardware bag, fasten the landing gear to the bottom of
the fuselage as shown.
7. Place the wheels on the ends of the landing gear struts and
secure them with the supplied wheel collars. Place a wheel collar
on both sides of the wheel. Use thread lock on the wheel collar
screws.
CONTINUED
Section 10: Installing the Main Landing Gear
