Section 13: Installing the Spinner
1. Remove the propeller nut and prop washer from the engine.
Locate the spinner, spinner back plate and two screws.
2. Install the spinner back plate on the engine crankshaft. Place
the propeller on the crankshaft and position it so it seats
correctly against the spinner back plate. Next, install the engine
washer and the prop nut onto the crankshaft and tighten
securely.
3. Attach the spinner to the spinner back plate using the two
screws provided in the hardware bag.
• Spinner
• Spinner back plate
• Spinner screws (2)
• Fuselage with motor mounted
• Phillips screwdriver (medium)
Parts Needed Tools and Adhesives Needed
