6. Close the lamp shell, screw the bolt and
fasten up the decorative frame.
Rear combination lamp
Take apart the rear combination lamp from the
overhead guard, pay attention to the safety
1. Take the whole rear combination lamp to
the service place, take off the lamp housing,
and screw off the four bolts at the back of the
lamp housing
2. Take off LED plate, loosen two bolts fixed
the connector, cut the connector, and change
a new LED plate.
3. The installation procedure is contrary to the
disassembly.
