6.Others
1. Fuse, relay
① Please first find out the reason before
replace damaged fuse or relay.
②Replace with regulated standard fuse
The Control box of forklifts are placed on left
side of truck frame.
2. Change of tires
Warning
• When using an air compressor, first
adjust the air pressure of the compressor.
Failure to do so will cause a serious
accident, since the compressor delivers the
maximum pressure.
• To ensure safety, put the tire in a
defend casing while inflating.
Front wheel
①Park forklift truck on level concrete;
② Start engine and raise mast about
100mm height.
③ Place chocks behind rear wheels to
prevent movement of forklift;
④ Loosen wheel nuts 1-2 turns each by
turning them counter-clockwise;
⑤ Tilt mast fully backward, and place a
wooden block under each side of outer
mast;
⑥ Tilt mast forward until front wheels
are raised from surface;
Caution
Do not loose nuts before the front wheels
leave the ground.
⑦ Support truck by putting wooden
blocks under both sides of the front truck
frame. Stop the engine.
⑧ Take out the wheel nuts and replace
the front wheel.
Caution
a. When removing tire from wheel rim, do
not remove rim set bolts and nuts before
releasing air;
b. Make sure that wooden blocks used to
support lift truck are solid, one-piece units.
c. Never get under forklift while it is
supported only by wooden blocks.
⑨ Retighten the wheel nut temporarily.
⑩ Start the engine, and take out the
wooden block.
○
11
Tilt backward the mast and lower
down the mast slowly, then take out the
wooden block under the outer mast and
rear wheel.
○
12
Retighten the wheel nut with correct
torque.
○
13
Adjust tire pressure to specified
value.
