HANGCHA CPCD25-XW98E-RT2 - Page 83

79
Model
CPCD35-XW43C-RT4
CPCD30-XW43C-RT4
Rated capacity
kg
3500
3000
Load centre
distance
mm
500
500
Overall maximum
lift height
mm
3000
3000
Free lift height
mm
150
145
Maximum lift
speed (with load)
mm/s
490
490
Tilt of the mast
F/B
10°/12°
10°/12°
Max travel speed
(without load)
km/
h
24
25
Ground clearance
mm
245
245
Min outside
turning radius
mm
3300
3300
Max. Grade ability
(Full load)
%
50
52
Wheel-base
mm
1880
1880
Service mass
kg
5600
5340
Overall dimension
(L × W × H)(include
forks)
4320×1599×2 420
4320×1599×2 420
Tyre (F/R)
14.5-17.5-14PR/2
10.0/75-15.3-14PR/2
14.5-17.5-14PR/2
10.0/75-15.3-14PR/2
Battery V/ capacity Ah
12/90
12/90
Diesel engine
Model
Cummins, QSF2.8T3NA49
Cummins, QSF2.8T3NA49
Rated
capacity/rpm
36.5kW/2500r/min
36.5kW/2500r/min
Max torque/rpm
186N·m/ 1500 r/min
186N·m/ 1500 r/min
Displacement L
2.8
2.8
