84
Model
CPCD25-XW33C-RT4
Rated capacity
kg
2500
Load centre
distance
mm
500
Overall maximum
lift height
mm
3000
Free lift height
mm
140
Maximum lift
speed (with load)
mm/s
620
Tilt of the mast
F/B
10°/12°
Max travel speed
(without load)
km/h
26
Ground clearance
mm
235
Min outside turning
radius
mm
3300
Max. Grade ability
(Full load)
%
60
Wheel-base
mm
1880
Service mass
kg
4850
Overall dimension
(L×W×H)(include forks)
4305×1557×2 390
Tyre (F/R)
12-16.5-14PR/2
10/75×10-15.3-14PR/2
Battery V/ capacity Ah
12/90
Diesel engine
Model
YANMAR 4TNE98
Rated
capacity/rpm
42.1kW/2300 r/min
Max torque/rpm
186N·m/1700 r/min
Displacement L
3.319
