88
Model
CPCD25-XW98E-RT2
Rated capacity
kg
2500
Load centre
distance
mm
500
600
1100
Overall maximum
lift height
mm
3000（3m mast）
6000（6m mast）
Maximum lifting
height lifting weight
kg
2500(3m)
600(6m)
2280(3m)
540(6m)
1600(3m)
380(6m)
Free lift height
mm
140
Maximum lift
speed (with load)
mm/s
620（3m mast）
610（6m mast）
Tilt of the mast
F/B
10°/12°
Max travel speed
(without load)
km/h
26
Ground clearance
mm
240
Min outside turning
radius
mm
2900
Max. Grade ability
(Full load)
%
29
Wheel-base
mm
1880
Service mass
kg
4670（3m mast）
5120（6m mast）
Overall dimension
(L×W×H)(include forks)
4205×1557×2 390
Tyre (F/R)
12-16.5-14PR/2
27×10-12-12PR/2
Battery V/ capacity Ah
12/90
Diesel engine
Model
Kubota V2607-CR-TE5B
Rated
capacity/rpm
47.3kW/2400 r/min
Max torque/rpm
221.7N·m/1500 r/min
Displacement L
2.615
