Hansen MCV User Manual

8
R649c
SEPTEMBER 2018
AMMONIA SUCTION VAPOR CAPACITIES, TONS
MOTORIZED CONTROL VALVE CAPACITIES
Reduced Capacity V-Ports shown in gray.
For best control and modulation, size the MCV valve for both the full load capacity and the minimum load capacity
(weekend load). The minimum load capacity should be at least 15% of the full load capacity. The capacity tables are
conservative, so it is not necessary to add a safety factor for capacity.
Ammonia, R-22 and R-134a capacities assume 86ºF (30ºC) condensing, except -40ºF (-40ºC) assumes +20ºF (-7ºC)
liquid (e.g. two stage). R-404 and R-507 assume 95ºF (35ºC) condensing. For overfeed evaporator suction, add 20% to
the evaporator load or use next larger size valve to accommodate liquid volume.
AMMONIA SUCTION VAPOR CAPACITIES, KILOWATTS
Evap.
Temp.
Pressure
Drop
3/4˝ 1˝ 1-1/4˝ 1-1/2 ˝ 2˝ 3˝ 4˝
ºF
(psi) MCR MCV MCR MCV MCR MCV MCR MCV MCR MCV MCR MCV MCR MCV
40
.25 1.5 4.2 2.7 8.0 3.7 11 8.2 24 11 32 24 71 32 113
.50 2.1 6.0 3.7 11 5.4 16 12 34 15 45 34 100 45 160
1.0 2.9 8.5 5.3 16 7.4 22 16 48 22 64 47 141 64 226
2.0 4.1 12.0 7. 3 22 10 31 23 67 31 90 67 199 90 317
5 6.5 19 12 35 16 49 36 106 48 142 106 315 142 501
10 9.2 27 16 49 23 69 51 150 69 201 150 445 201 709
15 11.3 33 20 60 28 85 63 183 84 246 183 – 246 –
20 13.0 38 23 70 33 98 73 212 97 285 212 – 284 –
0
.25 1.0 2.8 1.7 5.1 2.4 7.1 5.1 15 6.8 20 15 45 20 72
.50 1.3 3.9 2.4 7.1 3.4 10 7. 2 21 9.9 29 21 63 29 101
1.0 1.9 5.5 3.3 10 4.7 14 10 30 14 40 30 89 40 142
2.0 2.6 7.6 4.7 14 6.7 20 14 42 19 56 42 142 56 197
5 4.1 12 7.4 22 11 32 23 66 30 89 66 196 88 311
10 5.8 17 10 31 15 45 32 94 43 125 93 277 125 441
-40
.25 0.7 1.9 1.1 3.4 1.6 4.7 3.4 10 4.8 14 10 30 14 48
.50 0.9 2.6 1.6 4.7 2.2 6.6 4.8 14 6.5 19 14 42 19 67
1.0 1.2 3.6 2.2 6.5 3.1 9.2 6.9 20 8.9 26 20 58 26 93
2.0 1.7 4.8 2.9 8.8 4.0 12 8.9 26 12 36 27 79 35 125
Cv 2.2 6.4 3.9 11.7 5.5 16.4 12 35 16 47 35 104 47 166
Evap.
Temp.
Pressure
Drop
20 MM 25 MM 32 MM 40 MM 50 MM 80 MM 100 MM
ºC
(bar) MCR MCV MCR MCV MCR MCV MCR MCV MCR MCV MCR MCV MCR MCV
5
.02 5.4 16 10 30 14 42 30 90 41 123 91 271 125 433
.04 7. 6 23 14 42 20 59 43 128 58 175 129 383 177 613
.08 11 33 20 60 28 84 60 180 82 247 183 542 250 867
.15 15 45 27 82 39 115 82 247 112 338 250 742 343 1,187
.4 24 73 44 134 63 188 134 403 184 552 408 1,212 560 1,938
.6 29 90 54 164 77 230 165 494 225 676 500 1,484 685 2,374
1.0 38 116 70 212 100 297 213 638 290 873 646 – 885 –
1.4 45 137 83 251 118 351 252 755 343 1,033 764 – 1,047 –
-20
.02 3.1 9.5 5.8 18 8.2 24 18 53 23 70 53 156 72 249
.04 4.4 13 8.2 25 12 35 25 74 33 99 75 221 102 352
.08 6.2 19 12 35 16 49 35 105 47 140 105 313 144 498
.15 8.5 26 16 48 22 67 48 144 64 192 144 428 197 682
.4 13.9 42 26 78 37 109 78 235 104 314 236 699 322 1,114
.6 17.0 52 32 96 45 134 96 288 128 384 289 856 394 1,364
-40
.02 2.2 7 3.9 12 5.5 16 11 34 16 47 35 105 48 168
.04 3.0 9 5.5 17 8 23 16 49 22 67 50 149 69 238
.08 4.3 13 8 23 11 33 23 69 32 95 71 210 97 336
.15 5.9 18 11 32 15 45 31 94 43 130 97 288 133 460
Kv 1.8 5.5 3.3 10 4.7 14 10 30 13.3 40 30 89 40 142
