Hansen MCV User Manual

43
R649c
SEPTEMBER 2018
1/16˝(2mm) THRU 9/32˝(7mm) MCXV
MOTORIZED CONTROL VALVE PARTS LIST
3/4˝(20mm) THRU 4˝ MCV/MCR
ValveType
1 2 3 4 SMVConversionKits
PortSize ActuatorKit
Needle/V-port
AssemblyKit
(includesgasketkit)
Cartridge
AssemblyKit
(gasketkit,cartridge,
grease)
GasketKit
SMVtoMCV
ConversionKit**
(Actuator,DongleCable,
Bonnet,Bolts,Cartridge
Gasket,BonnetO-ring,
Grease)
SMVPowerCloseto
MCVPowerBackup
ConversionKit**
Inch(mm) Standard PowerBackup P/N Cv
MCXV/A
7/32"(5)
75-1331
75-1331
with
HUPS
75-1360 0.6
75-1358 75-1357*
75-1363
75-1363
with
HUPS
MCXV/B
9/32"(7) 75-1361 1.1
75-1364
75-1364
with
HUPS
MCXV/C
1/16"(2)
75-1359
0.2
75-1362 75-1362withHUPS
MCV
3/4"(20)
75-1332
75-1332
with
HUPS
75-1381
6.4
75-1325 75-1322 75-1318 75-1318withHUPS1"(25) 75-1382 11.7
1-1/4"(32) 75-1383 16.4
1-1/2"(40)
75-1333
75-1333
with
HUPS
75-1384 35
75-1326 75-1323 75-1319 75-1319
withHUPS
2"(50)
75-1385
47
3"(80) 75-1334
75-1334
with
HUPS
75-1396 104 75-1349 75-1351 75-1347*** 75-1347
withHUPS***
4"(100) 75-1392
75-1392
with
HUPS
75-1400 166 75-1350 75-1352 75-1348*** 75-1348
withHUPS***
MCR
3/4"(20)
75-1332
75-1332
with
HUPS
75-1386 2.2
75-1325 75-1322 75-1318 75-1318
withHUPS
1"(25)
75-1387
3.9
1-1/4"(32)
75-1381
6.4
1-1/2"(40)
75-1333
75-1333
with
HUPS
75-1388
12
75-1326 75-1323 75-1319 75-1319withHUPS
2"(50) 75-1389 16
3"(80) 75-1334
75-1334
with
HUPS
75-1394 35 75-1349 75-1351 75-1347*** 75-1347
withHUPS***
4"(100) 75-1392
75-1392
with
HUPS
75-1398 47 75-1350 75-1352 75-1348*** 75-1348
withHUPS***
NOTE:GasketsandO-ringsshouldbereplacedwithnewiftheyareremovedfromvalve.Recommendtolubricatenewgaskets/O-ringswithoilpriortoinstalling.Bolts
shouldhaveanW-seizeapplied.
* Includesstrainer
**All SMV to MCV conversion kits REQUIRE MCT to be available for conversion
*** All 3” and 4” SMV to MCV conversion kits REQUIRE a V-port kit to be requested separately
