Hantek 1008 - Input Connectors

0 -
D D
Z\
Input Connector
CH1/.../CH8: Input connectors for waveform display.
CAL: Probe compensation output.
Other Connector:
USB Port: Connect the B-Type Plug of USB cable to this port.
Power Supply
: Built in waveform generator.
GND.: A ground terminal- not installed in this version.
7
Hantek 1008
DIGITAL OSCILLOSCOPE
