, CH5, CH6,CH7 CH88 MATH.
CH3,CH4
Measure Signal
Cursor Menu
Click “Cursor” in main menu.
This method allows you to take measurements by moving the cursors
.
1. Source
The user can set the source to CH1, CH2,
and
When you use cursors, be sure to set the Source to the waveform on the display that
you want to measure.
2. Type
There are four types of cursors: Cross, Trace, Vertical and Horizontal.
8
55
Hantek 1008
DIGITAL OSCILLOSCOPE
