Logic Analyzer
Hantek4032L
Hardware Specification
Sampled channels 32
High input impedance 200K (C=10p)
Input voltage range -60V~60V
Logic threshold Range -6V~6V
Max Sample Rate 400 MSa/s
Max input Signal bandwidth 150 MHz
Min time resolution 2.5ns
Sample Depth 64M
Buffer Depth 2G
Trigger’s Max rate 200 MHz
Compatible input
TTL,LVTTL,CMOS,LVCOMS,ECL,PEC
L,EIA
Electrostatic Protected 15KV
Power Adapter 5V
Temperature range -10℃~60℃
Dimension
Length: 105mm Width: 80mm
Height: 25mm
Weight 0.38Kg
Accessories
A USB cable; A set Little Test Hook;
A Power Adapt; A Logic Analyzer Cable
A CD;
User’s Manual 35
