Hantek 4032L User Manual

Logic Analyzer
Hantek4032L

Channels
Level A
Pin Number Wire ID Wire Color
1 Ground Black
2 ACLK Grey
3 Ground Black
4 A0 Grey
5 A1 Grey
6 A2 Grey
7 A3 Grey
8 A4 Grey
9 A5 Grey
10 A6 Grey
11 A7 Grey
12 A8 Grey
13 A9 Grey
14 A10 Grey
15 A11 Grey
16 A12 Grey
17 A13 Grey
18 A14 Grey
19 A15 Grey
20 AST0 Grey
Level B
Pin Number Wire ID Wire Color
1 Ground Black
2 BCLK Grey
3 Ground Black
4 B0 Grey
5 B1 Grey
6 B2 Grey
7 B3 Grey
8 B4 Grey
9 B5 Grey
10 B6 Grey
11 B7 Grey
12 B8 Grey
13 B9 Grey
14 B10 Grey
15 B11 Grey
User’s Manual 36
