8 Technical Reference
8.1 MS1000 Enclosures
 The MS1000 enclosures are steel, wall-mounted, have a protection rating to IP66 and
EN6529/10.91 and comply with NEMA12.
 The MS1000 case will be supplied in the most appropriate size for the required number
of Output Cards to be fitted.
 Thedimensions of the case will be stated in the Notes section on the wiring diagram.
 The large and extra-large cases may require more than one person to carry them.
Appropriate wall mounting options should be discussed prior to supply and installation.
 Cable glands are provided on the lower panel to allow entry of wiring from connected
equipment (e.g. EMS/BMS analogue input cards).
8.1.1 Standard Case (Code N001)
Case Height 400mm
Case Width 300mm
Case Depth 200mm
Mounting Centres 355mm x 255mm
Case Material Steel, powder coated finish
Protection Rating IP66 to EN6529/10.91 complies with NEMA12
8.1.2 Large Case (Code N016)
Case Height 500mm
Case Width 400mm
Case Depth 200mm
Mounting Centres 455mm 355mm
Case Material Steel, powder coated finish
Protection Rating IP66 to EN6529/10.91 complies with NEMA12
8.1.3 Extra Large Case (Code N051)
Case Height 700mm
