MS1000 Control System
Installation Guide
hanwell.com
Page 23 of 30 GD6063-1
Case Width 500mm
Case Depth 250mm
Mounting Centres 455mm 655mm
Case Material Steel, powder coated finish
Protection Rating IP66 to EN6529/10.91 complies with NEMA12
8.1.4 MS1000 Output Card Case
The MS1000 Output Card is fitted into a DIN rail mountable Case.
Case Height 112mm
Case Width 100mm
Case Depth 23mm
Case Material ABS
8.2 Allowable Temperature and Humidity Ranges
Operating -20 to +50C
Storage -40 to+70C
Operating 10 to 90% RH non-condensing
Storage 5 to 95% RH non-condensing
