4. Trend screen
The screen shows the channel measurement with the graph. The graph displays the
currently measured value and flows regardless of the saving. The flowing speed of the
graph depends on the saving period.
Fig. 19) Trend screen
Go to the menu screen.
Go to the digital screen.
The icon blinks when the reserved
operation is configured.
Click to show or hide the grid.
Display the measured value with the figure.
Click to hide or show the graphs for each
channel. If hidden, the data do not appear
but the record keeps going in the internal
memory or the SD card.
Display the measured value with the graph.
Fig. 21) Trend screen - Hide the grid Fig. 22) Trend screen - Hide some channels
Fig. 20) Trend screen - Screen during the reservation
