HANYOUNG NUX GR200 Series User Manual

Graphic Recorder
38
Specifications
1. Input specification
Input type Measurement range (°C) Measurement range (°F) Degree
Thermoresistor
(RTD)
Pt100 Ω
Pt-0 -200 ~ 640 -300 ~ 1180
±0.15 % of F.S ±1digit
Pt-1 -200.0 ~ 640.0 -300.0 ~ 1180.0
Pt-2 -100.00 ~ 150.00 -300.0 ~ 1180.0
KPt100 Ω
KPt-0 -200 ~ 500 -300 ~ 1000
KPt-1 -200.0 ~ 500.0 -300.0 ~ 1000.0
KPt-2 -100.00 ~ 150.00 -300.0 ~ 1000.0
Thermocouple
(TC)
K
K-0 -200 ~ 1370 -300 ~ 2500 ±0.15% of F.S ± 1digit
K-1 -200.0 ~ 1370.0 -300 ~ 2500 ±0.15% of F.S ± 1digit(*2)
J -200.0 ~ 1200.0 -300 ~ 2300 ±0.15% of F.S ± 1digit(*2)
E -200.0 ~ 1000.0 -300 ~ 1800 ±0.15% of F.S ± 1digit(*2)
T -200.0 ~ 400.0 -300 ~ 750 ±0.15% of F.S ± 1digit(*3)
R 0.0 ~ 1700.0 -0 ~ 3100 ±0.15% of F.S ± 1digit(*4)
B 0.0 ~ 1800.0 -0 ~ 3300 ±0.15% of F.S ± 1digit(*1)
S 0.0 ~ 1700.0 -0 ~ 3100 ±0.15% of F.S ± 1digit(*4)
L -200.0 ~ 900.0 -300 ~ 1300 ±0.15% of F.S ± 1digit(*2)
N -200.0 ~ 1300.0 -300 ~ 2400 ±0.15% of F.S ± 1digit(*3)
U -200.0 ~ 400.0 -300 ~ 750 ±0.15% of F.S ± 1digit(*3)
Wre 5-26 0.0 ~ 2300.0 -0 ~ 4200 ±0.15% of F.S ± 1digit(*4)
PL-Ⅱ 0.0 ~ 1390.0 -0 ~ 2500 ±0.15% of F.S ± 1digit
VDC
-10 - 20 ㎷ -10.00 ~ 20.00
±0.15 % of F.S ±1digit
※ The current input
(4 - 20 ㎃ DC) is
available when you
use resistance 250
Ω (0.5 W / 0.1 %)
on input terminals.
0 - 100 ㎷ 0.00 ~ 100.00
1 - 5 V 1.00 ~ 5.00
0 - 30 V 0.00 ~ 30.00
VDC
Thermocouple
(TC)
K, J, E, T, R, S, B, N IEC 584
PL-Ⅱ, Wre 5-26 ASTM E988
U, L DIN 43710, IEC 751
Thermoresistor
(RTD)
Pt100 Ω DIN IEC 751
KPt100 Ω JIS C1604-1989 (OLD)
[ Range configuration for the input types ]
[ Specification for the input ]
(*1) 0 ~ 400℃ : ±5% of F.S ± 1digit
(*2) -200 ~ -150℃ : ±0.2% of F.S ± 1digit
(*3) -200 ~ -150℃ : ±0.4% of F.S ± 1digit
-150 ~ -100℃ : ±0.2% of F.S ± 1digit
(*4) 0 ~ 200℃ : ±0.2% of F.S ± 1digit
